22.5x9.00 Northstar 10x285mm Satin Black "Lunar" Hub Pilot Front

Northstar 22.5” x 9 Forged Aluminum Front Wheel – Satin Black

10-Hole Hub Pilot | 285.75mm Bolt Circle | Steer, Lift, or Pusher Axle

Upgrade your truck or bus with the Northstar 22.5 x 9 Satin Black Forged Aluminum Wheel, designed for steer, lift, and pusher axle applications. Built for strength, durability, and modern style, this wheel features a sleek satin black finish that delivers a bold look while standing up to the toughest road conditions.

With its hub-piloted 10-hole design, 285.75mm bolt circle, and 220mm center bore, the Northstar wheel ensures precise fitment and balanced performance. Engineered to handle heavy-duty commercial applications, it supports a maximum load capacity of 9,900 lbs at 130 PSI.

Wheel Specifications

• Size: 22.5” x 9

• Finish: Satin Black (Front)

• Position: Steer, Lift, or Pusher Axle

• Bolt Pattern: 10-Hole Hub Pilot, 285.75mm Bolt Circle

• Hub Bore: 220mm

• Offset: 7”

• Bolt Hole Diameter: 26mm

• Max Load: 9,900 lbs @ 130 PSI

• Warranty: 5 Years

Approved Tire Sizes

• 315/80R22.5

• 295/60R22.5

• 12R22.5

Replaces OEM/Comparable Parts

• Alcoa 89U64x

• Accuride 29730, 41730

Typical Applications

• Large Buses & Motor Coaches

• Heavy-Duty Truck Steer Axles

• Lift Axles & Pusher Axles

Key Features

• Forged Aluminum Construction – Combines maximum strength with significant weight savings over steel.

• Premium Satin Black Finish – Provides a bold, corrosion-resistant appearance.

• Heavy-Duty Capacity – Rated for up to 9,900 lbs at 130 PSI, perfect for commercial and vocational fleets.

• Precision Fitment – Hub-piloted 10-hole design ensures reliable mounting and performance.

• Warranty Protected – Backed by a 5-year manufacturer warranty.

The Northstar 22.5 x 9 Satin Black Forged Aluminum Wheel delivers strength, efficiency, and aggressive styling—making it the ideal upgrade for buses, motor coaches, and Class 8 trucks running steer, lift, or pusher axle applications.
